Automobile electric winch fixed fulcrum

If you want to pull the car forward, there must be a safe place fixed pivot, the fulcrum must also be able to bear the full weight of the car. The most basic principle is to move in front of the car pulled, do not appear angle. Off-road driving, the most commonly used fulcrum is the tree. However, if the Fromwinch best 4x4 winches to rescue another car was trapped, rescue vehicles can also be used as fulcrum, but in this case, we must block the wheel, so that it can not scroll, that is to ensure that rescue vehicles will not move.
No matter what kind of winch, if there is no safety fulcrum, you can not give full play to its potential. In other words, the fixed fulcrum is the use of winch is a crucial step.
In the use of Fromwinch electric wireline winch, also need a strap to connect the winch, fulcrum and wicker hook and U-shaped lug. If the winch does not have enough power to drag the weight with a single line, you need to use two-wire to enhance its strength, then also need a tight line pulley.
Another point to note that with the tree as the fulcrum, to use the widest part of the tape, so as not to Le belt to the tree to destroy the trees, and be sure to tape the left and right ends were tied to the hanging ears on both sides of the The length of the tape should be the same.

Electric winch installation

The use of the Fromwinch 4000lbs electric winch must of course start with the installation. This step is not complicated, but it is the most important step, because it is directly related to the subsequent steps and the use of winch effect. The most important thing here is to pay attention to the status of the noose drum, before the start and the entire process must ensure that the use of a uniform winding twist. Specific installation process is as follows:
    1. Insert the remote control. Insert the remote control connector end into the winch.
    2, do not let the remote control hanging drape. If you are a driver, operating the remote control in the driver's seat, then the excess connection around the side mirrors in the car side, the work will be much more convenient.
    3, pull the noose, with the remote control cable will release a little point and then open the Fromwinch two motor winch installed on the side of the noose hook.
    4, open the clutch. Be sure to turn on the hook and then turn the clutch on again.
    5, hand-held noose hook. When the noose is pulled down from the drum, hold the hook with one hand, so that no matter how long it is pulled, it will not be able to reach the hook.
    6, will be pulled to the fulcrum fulcrum, lock the clutch.
    At this point the winch is ready.

Off - road vehicle electric winch

Fromwinch electric wire winch is obtained from the car itself to drive the motor drive noose. This type of winch is convenient because it can be operated anywhere from the knobs on the remote control. It is the biggest advantage is that as long as the battery power can be used.
However, the power of the Fromwinch electrical cable winch motor is generally only a few horsepower, so how can a small power motor to drag a heavy car or other heavy objects it? Secret in the use of reducer. Even if the motor can only send a small force, but the reducer can be transformed into a powerful force. Different winch manufacturers use this principle is to create a different product.
Most winchs on the market use planetary gears as reducers. Planetary gear has the advantage of smaller size and the resulting relatively large reduction ratio, and the gears of the contact points more long service life. Fromwinch 4000lb atv winch is usually installed in a small space, so the smaller the lighter the better. Planetary gears can achieve this requirement, but also produce a larger reduction ratio, so again ideal.
Simply put, the working mechanism inside the winch is: the electric power from the car to drive the motor first, and then drive the drum motor rotation, drum and drive the drive shaft, the drive shaft and then drive the planet gear, and then have a strong torque. Subsequently, the torque is transmitted back to the drum, the drum will drive the winch. There is a clutch between the motor and the gear unit that can be switched by a handle. Braking unit in the drum, when the noose tension, the drum is automatically locked.

How to Operate Electric Winch Properly

First, the Fromwinch competition auto Winch must be easy to see on the place, not on the inconspicuous corner, and must be safe and open place. The traction macro diverter pulley should be installed at a distance not less than 40 times the length of the drum. Height must exceed the wooden stack 2-3 meters, is strictly prohibited in the crib on the guide pulley. Operation of the time need to focus on the operation when the rigorous operation of more than one person, run time, is strictly prohibited all personnel into the rope angle zone. In the inspection and maintenance, we found that one of the following circumstances wire rope must be re-replaced or scrapped: foreign wire wear to wire diameter of one-half; in a pitch within the number of broken wire 6-8 apply; The use of wire rope, the pitch elongation of 10% of a wire all broken, there are dead ends or serious corrosion of wire rope.
Second, before starting the Fromwinch electrical cable winch machine, you should check whether there is a sufficient number of oil in the transmission, the need for lubrication of the parts have been lubricated, the gear teeth and teeth between the debris. In winter, the lubricating oil in the gear reducer tends to condense, so check the shaft of the inspector before starting. When starting the electric winch, brake the reel, open the electrical switch, connect the necessary gears in the gear unit, and then link the motor Of the clutch, that is, to rotate the reducer shaft.

We are the well known manufacturers and suppliers of electric wire winch.

We are the well known manufacturers and suppliers of electric wire winch. Fabricated from best quality raw material our range is appreciated for dimensional accuracy, robust construction and operational efficiency. The electric wire winch offered by us are used in repair jobs and to carry out erections. The winches can also be custom made in accordance with the load lifting capacity.
Fromwinch electric winch manufacturers

, from where you can buy the right kind of winches for your perusal. Whenever you are buying winches, make sure that check the line being used in the winches. There are few hydraulic winch manufacturers , who tends to use the steel cable which works amazingly even if expose to great amount of heat. These lines are also made from synthetic rope which melts quite easily when exposed to heat therefore it is better to avoid such winches. However, it is true that the synthetic ropes are less prone to dangers if it is broken due to accidents. With the availability of many electric winch manufacturers, it has become quite easy to get winches that have both the features.

Electric atv winch features

Electric atv utv winch features:
1)All metal, high precision, high strength of the 3 planetary gear groups
2)Waterproof motor
3)Long-life sealed control switch
4)Full sealed large current contactor
5)Install four power wire convenient
6)Hot-dip galvanized steel for air level
7)Included components: mounting plate, roller fairlead, G70 hook, contactor, handle switch, portable truck winch

sets, hardware, hand saver strap,
8)Sheath of rubber, ribbon, instruction, EPS packaging, colored box and more
9)Small volume, light weight, strong tension and more
10)Suitable for small SUV, beach all-terrain vehicle and light vehicle outdoor operation.

Be prepared for anything with our selection of atv utv winch, recovery kits and accessories

Be prepared for anything with our selection of atv utv winch

, recovery kits and accessories. For those that own an ATV or UTV, you know it’s always necessary to carry equipment in the event you need to tow, haul or recover from a fall off the trail. This is one area where you don’t want to buy cheap or poorly made equipment. We carry synthetic ATV winch ropes, ATV/UTV winches, recovery gear, trail gear,  winch line saver, winch isolaters, ATV winch hooks, UTV accessories and Winch Cable Dampener. We’ve made it so you can purchase items individually or in a kit for ease.
For ATV’ers going out on a trail ride, make sure you’re prepared with ATV accessories like a first aid kit, a recovery shovel, a 5-in-1 tool (axe, shovel, pick, saw and compass), a hatchet, a commando axe and a flashlight.

Off-road vehicles due to poor driving conditions, often equipped with Fromwinch competition car Winch as a self-help device. When the car wheel into a particularly loose to save the soil, or in the ice on the road can not travel, and fall into the pit of the hinge, you can use the twist to the end of the rope fixed in a nearby reliable location. 2. The winch rope twisted by the engine lifted the car out of the woods.
See also You can also use it to rescue other troubled vehicles.
Fromwinch electric winches for trucks mainly by force box, drive shaft, winch, reducer, drum Jane and automatic brakes and accessories and other components.

Off-road vehicle winch What is the use

fromwinch competition car Winch in the industry is actually a hoist, is a very common machine, many factories are able to see them. Winch in the application of off-road vehicles are more, when the car into a quagmire bunker or a steep slope when unable to move, we must rely on winch to save, fromwinch 12500lbs electric winch can make your car from 4X4 into 4X5. Therefore, many people will own the car winch called the fifth drive, electric winch has been the main form of off-road vehicles with the winch.

Installation and Principle of Electric Winch for Automobile Safety

If the car stuck in any place and can not extricate themselves, then the most reliable tool is the electric winch. If you learn to use the electric winch correctly, you can cross-country encountered in the course of emergency self-help and rescue each other calmly, so as to maximize the enjoyment of the four-wheel drive cross-country fun.
fromwinch high speed electric winch installation
The use of an electric winch will of course start from the installation. This step is not complicated, but it is the most important step, because it is directly related to the subsequent steps and the use of electric winch effect. Specific installation process is as follows:
1. Insert the remote control. Insert the remote control connector end into the electric winch.
2, do not let the electric winch remote control hanging drape. If you are a driver, operating the remote control in the driver's seat, then the excess connection around the side mirrors in the car side, the work will be much more convenient.
3, pull the fromwinch atv synthetic winch rope cable, with the remote control will be released a little noose and then open the winch installed on the side of the noose hook.
4, open the electric winch clutch. Be sure to turn on the hook and then turn the clutch on again.
5, holding the electric winch with a hand noose hook. When the noose is pulled down from the drum, hold the hook with one hand, so that no matter how long it is pulled, it will not be able to reach the hook.
6, the electric winch cable to the fulcrum, the clutch.

Car winches in the car which part? What is the role?

fromwinch electric winches for 4x4 is divided into manual winch, electric winch, hydraulic winch, pneumatic winch and mechanical winch. Winch is a type of drivetrain in a car. Winch is a vertically mounted winch drum. It is a machine that can be rolled without power, but does not store a rope. It also refers to a winch that is perpendicular to the deck. Automobile winch is mainly used for off-road vehicles, agricultural vehicles, ATV all-terrain vehicles, yachts, fire rescue vehicles, road wrecker and other special vehicles, special vehicles. Car winch is the vehicle, the ship's self-protection and traction device, the car winch in the snow, swamps, deserts, beaches, muddy mountain road and other harsh environments for self-help and rescue fromwinch electric winch for tower and other conditions, , Towing items, installation facilities and other operations, car winch is the military police, petroleum, hydrology, environmental protection, forestry, transportation, public security, border defense, fire and other outdoor sports indispensable safety device.

The important role of car winch

1, in the mountains over the way, the roll is common, car winch can replace the crane to roll over, but must be hooked in the able position, otherwise the car winch will increase the damage to the body.
2, the marshes are not terrible, but if there is continuous emergence of groundwater it must be immediately pulled out with the car winch, because the water level rise very fast.
3, field recovery vehicle in addition to itself must be all-wheel drive, but also at least before and after the two fromwinch 4500lbs electrical winch. Car winch, pulling up to 4100 kg, followed by the PTO hydraulic car winch, pull up to 9500 kg, and the rear there is a trailer frame.
4, Discovery car winch did not put on the MT off-road tires, and did not increase the suspension system and differential lock, the off-road vehicle capacity and not imagined good, very easy to be stuck.
5, before entering the Shahe (bottom of the river is the sand), in addition to locking the differential, the fromwinch competition car Winch should also be out as soon as possible. Car modification waterproofing device is also necessary.
6, XX car has a great horsepower, before and after the differential lock lock up to 100% (45 degrees), but because the body is too heavy, in the swamp is easy to stuck, the street can not use the MT tire Pits, must use the car winch is not.
7, in the desert into the bunker, if not too deep can pull the cloth with the pull out, but if too deep must use the car winch, otherwise the two cars will sink at the same time.
8, boarded the 45 degrees (1: 1) slippery slope, the XX car also depends on the car winch, and add the pulley to double the tension. You can use the Upper Desert Bridge to help cross the V Valley when you pass the V Valley.
9, in the rapids, the winch is the only effective rescue tool, because the HiLiftJACK car winch can not start the desert board will give the water washed away.

How the manual winch works

Hand Winch fromwinch tungsten4x4 winch with manual longitudinal or circular motion as the driving force. Manual winch is the biggest advantage of portable, can be connected from any direction of the car. The hand winch is light and firm, electroplated, pressed steel, and the wire rope pulls the pulley propulsion unit through two default fork heads. These forks pull the steel cable in the manual winch forward mode, and are also an automatic brake system. The fork of the manual winch will automatically lock when the grip is increased. fromwinch winch for trucks can also be used for lifting (lifting force for the drag force of about 65%).

Rally core components of the car winch

An fromwinch jimmy winch power part of two: permanent magnet DC and string machine DC. The latter has a fast action, suitable for long work and cost higher "advantages"; the former is classical, simple structure and low cost of traditional forms. The first application of the car winch in off-road vehicles on the use of permanent magnet motor, when the battery capacity is low, and the permanent magnet motor just needs a smaller current. The current high-power motor also began to use string machine. To determine what kind of motor used in an fromwinch electric winches for 4x4, just look at the control box output to the motor part of the line number can be: two lines of the permanent magnet motor, three lines of the string machine.

What is the classification of car winch?

    There are many kinds of car winch, mainly electric car winch, mechanical PTO car winch, hydraulic PTO car winch, hydraulic car winch, etc., of which the most popular electric car winch is also the most familiar.
First, the electric car winch
    fromwinch 9600lb electric winch is from the car battery power to drive the motor, driving noose. This car winch is very convenient to use, because you can stand anywhere, through the remote control knob to manipulate the winch. This car winch has an advantage, that is, even if the engine does not start up, as long as there is electricity in the battery, you can control the winch.
Second, the mechanical PTO car winch
    Mechanical PTO car winch (Power Take Off) due to take power directly in the engine, so the torque is super, toughness and durability are very good, but the drawback is the car overturned, the engine can not be run can not be used, and its size, Weight is very large, very limited models for the application.
Third, the oil pressure PTO car winch
    Hydraulic PTO car winch need to install a special pump to connect the engine, not only heavier and more complex installation.
Fourth, the hydraulic car winch
    Hydraulic fromwinch electric winches for trucks pulling speed constant and not fast, it is also very complex to install, and it uses the original car steering power of the oil system will be "thin" of its oil pressure, not suitable for any car, to be modified Powerful booster pump was more at ease, but it is not too much heat trouble.

Key Points for Proper Operation of Electric Winch

How to correctly operate the fromwinch atv synthetic winch rope is very important, which relates to the safety and efficiency of the project.
The first is the location of the electric winch, electric winch machine must be easy to see where the electric winch is not placed in an inconspicuous corner, and the electric winch must be safe and open place.
Electric winch traction The diverter pulley should be installed at a distance not less than 40 times the length of the reel. Electric winch machine height must be more than 2-3 meters wooden stack, electric winch machine is prohibited in the crib on the guide pulley.
Electric winch operation when the need to focus on the operation of the electric winch when the rigorous operation of many people, run time, is strictly prohibited all personnel into the fromwinch electric winches for trucks rope angle zone.
In the electric winch inspection and maintenance, found that electric winch wire rope in one of the following circumstances must be re-replaced or scrapped: electric winch outside the home wire to wear wire diameter of one-half; in the electric winch a section Electric winch machine long-term use of wire rope, electric winch machine elongation of 10% of the lamp there is a wire all broken, electric winch wire rope on the knot or serious corrosion.

How to use electric winch

Electric winch in transportation safety is one of the important equipment in the correct purchase of fromwinch electric towing winch and the installation of electric winch, how to use electric winch to plague everyone, if you can not use the electric winch, the electric winch will be lost The meaning.
 Car off-road is now the young fashion entertainment, in the harsh natural environment such as snow, swamps, deserts, where they have not been to, can not be safe and sound. In their pre-departure will be prepared enough, then the electric winch is the most important car accessories.
1, over the mountains in the way, the roll is common, electric winch can replace the crane to roll over, but must be hooked in the position of force, electric winch, then it will increase the damage to the body.
2, the marshes are not terrible, but if there is continuous groundwater that must immediately pull out the fromwinch electric winch 3000lbs, because the water level rise very fast. Electric winch When the car into a dangerous situation, the electric winch wire rope tied out at a fixed point, the use of electric winch electric vehicle drive their own electric winch, electric winch by the electric winch by electric vehicle, With this force, you can make the car from difficulties. However, the electric winch does not have a remote control, can not control the speed, electric winch is an explosive force.

The importance of off - road vehicles winch

To be good fromwinch electric winches for trucks thing, must first benefit off-road vehicle winch. Cross-country is a sport loved by the majority of young people, but no professional off-road vehicle winch, blind to cross-country is absolutely very dangerous. Spend a lot of money to buy a similar Wrangler professional off-road tool is a good idea, but the cost of off-road vehicle winches are not affordable; and conversion ideas through a number of cross-country parts to modify a sport utility vehicle, seems to be a good Of the idea.
  Off-road vehicles winch off-road vehicles, "often in the river to go, how can not wet shoes," the reason even in his own body every time very lucky, but it will inevitably take place in the SUV winch his fellow, so equipped with SUV Winch is also essential, as the vehicle into the soil or sand in the most reliable rescue tools off-road vehicle winch, with off-road vehicle winch can be external power, fromwinch electric winches for 4x4 cable into the pull, off-road vehicle winch The car pulled out of trouble, of course, off-road vehicle winch can also help the driver to remove obstacles on the road.

The pulling force of the car winch, the core component and the motor type

 The average fromwinch heavy duty synthetic rope winch means the traction of the car winch, such as the car winch RAMSEY PRO PLUS 9500 refers to the car winch maximum traction force of 9500 pounds (1 pound of about 0.45 kg).
The principle of buying the car winch is generally 1.5 times the weight of the vehicle pulling force is appropriate. If the vehicle weight is 1600 kg, then the pull of the car winch should not be less than (2000 / 0.45) * 1.5 = 5333 pounds.
Car winches on the nominal model is the maximum pull, but the actual use of car winches this is a limit. If the vehicle for a long time in the engine under the limit of the car winch, car winch is bound to "break life."
Also in the car winch limit state, the car winch will be pulled off the cable, car winch motor burned the accident, the more serious will cause bystander victims, car winch car vehicles may also be out of control.
 The power part of an automobile winch has two kinds: permanent magnet DC car winch and string machine DC car winch.
String machine DC motor fromwinch 9600lb electric winch with fast action, string machine DC car winch for a long time and cost of high-string machine DC car winch and so on.
Permanent magnet DC car winch is the traditional permanent magnet DC car winch, simple structure, permanent magnet DC car winch and low cost permanent magnet DC car winch in the traditional form.
The earliest application of the car winch on the car when the use of permanent magnet motor vehicle winch, when the ability of car winch battery is low, and permanent magnet motor winch motor just needs a smaller current.
Judge an automobile winch with what kind of motor, just look at the control box output to the motor part of the line number can be: two lines is the permanent magnet motor winch motor, three lines is the car winch string machine.

Electric winch works

 Many types of car winch, electric car winch, the use of automotive engine mechanical power driven by the car winch and the use of hydraulic pump operation of the car winch, etc., off-road use of the largest number of electric winch.
Electric winch is to obtain power from the car itself to drive the motor drive electric winch rope. This electric winch is convenient because the electric winch can be operated anywhere from the knob on the remote control. Electric winch is the biggest advantage as long as the battery power can be used.
However, fromwinch 4500lbs electrical winch motor power of at most only 1-2 horsepower, such a small electric power winch motor how to drag a heavy car.
The secret is in the use of electric winch reducer. Even if the electric winch motor can only issue a small force, but the electric winch reducer is able to transform the power of the electric winch. Different manufacturers of electric winch is the use of this principle is to create a different product.
Most of the electric winch on the market are using planetary gear reducer. Electric winch planetary gear has the advantage of smaller electric winch reduction ratio is relatively large, and the electric winch gear contact points more, the use of electric winch longer life. Electric winch is usually installed in a narrow space, so the smaller the lighter the better. Electric winch planetary gear both to achieve this requirement, while generating a larger electric winch reduction ratio, so again ideal.

If your car is not before the trailer hook, the capstan wire hook on a certain part of the frame, and not hooked in such as the front axle, steering rods, shock absorbers or bumper, these parts can not withstand the pull of the winch, Will be bent or broken. The towline of the fromwinch 4WD Electric Winch line should be hooked up on the trailer hook so that the capstan line breaks or the tow hook slips down to the ground instead of flying into the air. Get the maximum tension can be easily dragged with a single line, more difficult to use the pulley should be dragged with two-lane. Use a small load of the fromwinch heavy duty winch cable or drag a particularly large load, you can even use three lines to obtain greater tension. Pull the capstan line out of the car and go back to the front of the car by the pulley on the tree-carrying belt, around the pulley on the trailer hook, and then back to the tree belt. This is the way to deal with most winch , But keep in mind that this method will make your fromwinch electric wire winch overload. With two or three lines, the cost of lifting the speed of the loss. Two-wire pull the car forward speed is half of the single-line, three-wire speed is one-third of the line.

Capstan line and fixed point connection can be single or double stranded capstan line. The fromwinch electric winches for trucks single wire means that the winch wire is pulled to a fixed point and hooked directly to the D-shaped lug, which is a single wire from the car to the tree. Two-wire fromwinch electric winch for tower can be doubled. A double pulley is required, a pulley with a metal hook, or a pulley that is attached to the D-lug with a different connector. Hook the pulley onto the bolts of the D-type eyebolts on the tree belt, pull the capstan line to the pulley, and open the pulley opening to wind the capstan line around the pulley. Pull the capstan line back into the car and hang on a front trailer hook attached to the frame.

Simply put, the working mechanism inside the winch is: the electric power from the car to drive the motor first, and then drive the drum motor rotation, drum and drive the drive shaft, the drive shaft and then drive the planet gear, and then have a strong torque. Subsequently, the torque is transmitted back to the drum, the drum will drive the fromwinch heavy duty winch cable. There is a clutch between the motor and the gear unit that can be switched by a handle. Braking unit in the drum, when the noose tension, the drum is automatically locked. In practical application, some auxiliary items are necessary for the safe and smooth use of the fromwinch 4500lbs electrical winch, such as gloves can protect the hand. In addition, if you want to winch fixed in a tree, but also need a strap, a u-shaped lifting ears and a tight line pulley. The strap is used to hold the fulcrum. The ideal length is 1.5-2. O-meter; u-shaped hanging ear hook and the winch can be connected with the band. So it is best to prepare several sizes of lifting ears; with two or three lines, change the drag direction, you need a tight line pulley. In short, the fromwinch 9600lb electric winch can be divided into three steps: installation, fixed pivot and drag.

How to use the winch and the precautions

If you want to pull the car forward, there must be a safe place to fix the fulcrum. Of course, the fulcrum must be able to bear the weight of all ATVs. The most basic principle is to car movement in front of the pull, do not appear angle. In the cross-country, the most commonly used fulcrum is the tree or rock, but if the fromwinch electric winches for 4x4 to rescue another car was trapped, rescue vehicles can also be used as fulcrum.
No matter what kind of winch, if there is no safety fulcrum, can not give full play to its ability. In other words, the fixed fulcrum is the use of winch is a crucial step.
In the use of winch, also need a strap or chain to connect the winch and fulcrum, and link the cable hook and U-shaped lug. If the fromwinch heavy duty synthetic rope winch does not have enough power to drag a heavy load with a single line, you have to double-line to enhance tension, and also need a splint pulley.
Another point to note, that is, with the tree as a fulcrum, we should try to use the widest part of the tree with the tree to do so in order to obtain a strong fulcrum, but also to protect trees from harm.

Advantages and disadvantages of electric winch

Electric winch has 2000-10000 pounds of specifications
Electric winch is the most common winch. Rely on the vehicle's own power system to drive the fromwinch 3000lbs atv winch, advantages: in the case of vehicle dead fire basic normal use (this is its biggest advantage is unmatched by other winch), especially for water and more areas have great advantages, simple to install To achieve multi-location installation and rapid shift. Disadvantages: can not maintain the use of a long time (the vehicle's own power system limitations, its easy to heat and other reasons), most fromwinch USA electric winch can provide a smaller driving force, can only exert force in one direction (installed in front of the vehicle only to the Front pull, installed in the rear can only pull back).

fromwinch electric clutch winch is the most common winch. Rely on the vehicle's own power system to drive the winch, advantages: in the case of vehicle fire dead normal use, is unmatched by the other fromwinch double motor winch, especially for water and more areas have great advantages, simple installation can be multi-location installation and rapid . Disadvantages: can not maintain the use of a long time (the vehicle's own power system limitations, its easy to heat and other reasons), most fromwinch electric towing winch can provide a smaller driving force, can only exert force in one direction (installed in front of the vehicle only to the Front pull, installed in the rear can only pull back).

The winch is a vertically mounted fromwinch 5500lb winch drum, which is capable of winding but does not store a rope under the power drive. It is also a fromwinch tungsten4x4 winch is perpendicular to the deck and is a self-protection and traction device for vehicles and ships. Marshes, deserts, beaches, muddy mountain road and other harsh environments for self-help and rescue, and in other conditions, the clearance barrier, drag goods, installation facilities, military police, oil, hydrology, environmental protection, forestry, , Public security, border defense, fire and other outdoor sports indispensable safety devices. Mainly used for off-road vehicles, agricultural vehicles, fromwinch atv winch with remote control all-terrain vehicles, yachts, fire rescue vehicles, road wreckers and other special vehicles, special vehicles.

The fromwinch 5500lb winch is the most Typical Sort of winch. It is the Least expensive and Calls for the Minimum modification to the Automobile, so it it reasonably Effortless to Get rid of it and Send it to your Following 4WD (a Actuality midnight spares are Properly Conscious of).
Electric winches can draw hundreds of amps which puts a Fantastic strain on the battery, alternator and the fromwinch 4500lbs electrical winch Change-Items if Employed for prolonged winching. They will Run if the Powerplant is Lifeless (e.g. in Drinking water) - Till the battery is flattened. It is Typical Exercise to Match dual batteries to cope with the Fill and to Depart from the Engine Operating Although fromwinch heavy duty synthetic rope winch to Maintain the batter(y|ies) charging to some Magnitude.

Winching is potentially Hazardous and some Basic precautions Will need to be Noticed. Retain innocent bystanders Nicely Aside; a winch Cable television can snap and lash Anybody in the vicinity. Do not use a snatch strap or other elastic Equipment with a fromwinch 12500lbs electric winch - you could be forming a Potent catapult. Use Powerful winching Factors - a stout tree (use a trunk Guardor), a buried Soil anchor, or One more Automobile. Use Decent Gear and discard Broken fromwinch double motor winch Cable television. Put on Hard gloves to Guard Arms from frayed strands of Cable television. Make Certain that the Cable television of a drum-winch feeds on in neat, uniform layers, but if you are feeding the Cable television in, keep Arms Nicely out from the fromwinch tungsten4x4 winch fairleads in Circumstance they are snagged and dragged in.

Winches are mounted on 4 wheel Generate Automobiles to Get better bogged Automobiles, to Proceed heavy objects, and as the ultimate in 4x4 Style Components. They are Generally mounted at the The front, which is not the Greatest Placement in A lot of Methods; it adds Pounds to a Automobile extremity and Could possibly Demand More powerful springs, and it Helps make fromwinch electric wire winch backwards Complicated or Not possible. Have you Actually been stuck nose in? (The Foers Method Permits a Center mounted fromwinch 3000lbs atv winch to Take to the The front and the
rear With out rethreading the winch rope.)

power electric winch with single drag heavy objects

When using the electric winch, but also a tree support strap to connect the electric winch, the fulcrum and the noose hanging hook and u shackle lock. If you do not have enough power electric winch with single drag heavy objects, you need to use the lane to enhance its efforts, this time also need a tight line pulley.
In practice, some aids are essential for safe and smooth when using the electric winch, such as gloves to protect hands safe. In addition, if you want electric winch fixed to a tree, but also a piece of string, hang a u-shaped ears and a tight line pulley. Tape is used to a fixed pivot Of. with two-or three-line, drag to change direction, you need a tight line pulley.

The working principle of electric winch and use

The working principle of electric winch and use
Many kinds of electric winch, the vehicle engine mechanical power-driven electric winch and electric winch with a hydraulic pump operation, etc., to use off-the largest number of electric winch up. car electric winch was the motor drive power to drive the noose of. This electric winch is very convenient because you can stand in any place through the knob on the remote control. It is the biggest advantage is that as long as the batteries have power, you can use.
However, the winch's power hold engineering promise to only a few horsepower, why such a small power to drag a heavy motor car or other heavy objects on it also? The secret lies in the use of reducer. Even if the power of the motor can only be issued by smaller, but the reducer was able to transform it into a force powerful.

Fromwinch electric winches are designed as per the set international norms

Fromwinch electric winches are designed as per the set international norms by using high grade tools. All these Industrial Electric Winches are appreciated by our clients for their reliable performance, easy usage, low maintenance and convenient handling. The Electrical Winch offered by us is widely appreciated by our clients for its robust construction, dimensional accuracy and operational efficiency. Offered electrical cable winch are used for material handling in various industries and they are highly suitable for diverse heavy-duty applications. In order to fulfil varied demands of our clients, our quality range of Electrical Winches is made available in various dimensions and capacities. Clients can avail this range from us at highly discounted rates in the market.

Tungsten4x4 winch features

Fromwinch electric winch manufacturers is engaged in offering an exclusive array of Electric Winches. Broadly used to adjusts the tension of a rope, the offered electric winches are made by utilizing high grade material and advance technology to make sure flawless at users' end. These electric winches are provided in various specifications to meet the requirements of the customers. We are providing these electric winches within the promised time frame at competitive rates to our customers.
Tungsten4x4 winch features:
Precisely engineered
Long life
Optimum strength

Tungsten4×4 heavy duty synthetic rope winch

The Tungsten4x4 electric winch provides 12000 lb line pull rating for smooth and efficient operation.The tungsten4x4 winch has water resistant seals and speedy line recovery. The Tungsten4x4 12000lbs. electric winch is equipped with 6.5 HP 12V DC series wound motor and automatic braking locks rope to prevent from spooling.
Tungsten4×4 heavy duty synthetic rope winch is made from top-grade materials and is designed for winches of 8000 lbs thru 12000 lbs.This rope will haul the load safely, without the problem of handling steel wire. It has the ability to stretch with load impacts, and comes without the problem of rusting like a steel cable. The rope is rated for a breaking strength of 15000 lbs. Compared with a steel cable, it only recoils a little when breaks and is much safer than a metal cable or a chain. Tungsten4×4 synthetic winch rope is lighter and easier to handle than a traditional wire rope.

Tungsten4x4 T4000 Atv/Utv Winch

Tungsten4x4 T4000 Atv Utv Winch
Water resistant seals. 1.6 HP DC permanent magnet motor. 3 stage planetary gear system.
Fast retrieval 198-1 gear ratio. Automatic load holding brake in drum. 4 roller fairlead.
6mm x 10m Atv synthetic winch rope. UV resistance for strength and durable. Standard ATV / UTV battery works well. Low amperage consumption.
Designed to be used for the larger ATV, UTV and car, boat, multi purpose utility trailers. This compact winch has a higher level of ability for those who require the extra power for tougher jobs. Simple and easy to use, this winch will make your day smoother when hauling a load on board or when used for self recovery.
mechanical spring brake for fast reaction while winching.
included wireless remote control for convenience operation.

The tungsten4x4 winch has water resistant seals and speedy line recovery

The Tungsten4x4 electric winch provides 8000 lb line pull rating for smooth and efficient operation. The tungsten4x4 winch has water resistant seals and speedy line recovery. motor and automatic braking locks rope to prevent from spooling.
9500lb 12V electric winch designed for trucks, jeeps, 4x4 off road, and modified vehicles used in self-recovery. Works well for car and boat towing trailers, Tractors, Forestry, Police and Fire department work. Can also be used in light industrial applications.
Farm jack base used as a universal lighter weight jack to help out of adverse circumstances. Great for changing big tires or propping yourself up higher to help get out of a hole. Easy to mount with its shorter length. Can be used for tightening wire fences and many other odd jobs.

Electrical Winch (ATV winch or Recovery winch)

ATV winches are Utilized when the rider Will get their Automobile stuck or want to haul Some thing heavy. The fromwinch electric truck winch is a Basic Device, That contains a casing and Metal Cable with a hook Connected to it. The Person just presses a Key on their winch or handlebars to detract the Cable television. The Cable television is then wrapped Close to an Item, This kind of as a tree. The Person then pushes that Exact same Key to engage the fromwinch high speed electric winch and draw the Cable television Back again into the casing, Transferring Possibly the ATV out of it’s stuck Location (This kind of as in a deep creek or in mud), or moves the Item it’s Linked to (This kind of as a downed tree, Lately Wiped out deer).Get out Quickly with an electric offroad winch from ProMark Offroad.
Every winch Arrives with Cable television (Metal or Artificial), fromwinch electric winch for tower controls, and an accessory Package to get you Started out. Mounting plates Marketed separately.

What to Glance for When Selecting a UTV Winch

How do you Utilize the Power Element of your fromwinch small suv winch? Are you Searching for A thing to Improve your Present Set up? Winches are Generally overlooked, but they complement any Aspect-by-Aspect’s Set up. Carry a look at these Critical Products to conAspectr when choosing a fromwinch Winch Cable Dampener.

Fromwinch designs and manufactures such electric winches to suit specific client requirements.

Fromwinch electric winch manufacturers is one of the Electric Winches leading brands in China. It is the factory and supplier specializing in manufacturing Electric Winches. Offer high quality electric winch at a cheap wholesale price.
Electric winches are used to push / pull loaded trolleys moving on rails. Electric winches come in different shapes and sizes. Electric winches are usually capable of handling loads of 1 ton to 200 ton. The cables and motors of electric winches are created specifically to handle different weight loads.
Electrical winches consist of five main parts, which is motor, coupling, brake, gear box and drum respectively. The five parts assembles in the same rack together. Electric winch has two obvious features. Firstly, it has great speed control performance according to high lifting altitude and heavy loads, which can make hook with loads decline in a extremely fast speed. And for accurate position loads and subtle loads, electric winch machine is able to adopt lower speed. Fromwinch designs and manufactures such electric winches to suit specific client requirements.

Tungsten4×4 winch rope is made from top-grade materials

Fromwinch tungsten4x4 winch rope is made from top-grade materials and is designed for winches of  including 4000lbs pulling. This rope will haul the load safely, without the problem of handling steel wire. It has the ability to stretch with load impacts, and comes without the problem of rusting like a steel cable. Compared with a steel cable, it only recoils a little when breaks and is much safer than a metal cable or a chain. Tungsten4×4 synthetic winch rope is lighter and easier to handle than a traditional wire rope.
Conveniently and safety.,Automatic braking locks rope to prevent free spooling. Designed to be used for the larger atv, utv and car, boat, multi purpose utility trailers. This electric winch has a higher level of ability for those who require the extra power for tougher jobs. Simple and easy to use, this winch will make your day smoother when hauling a load on board or when used for self recovery.

Tungsten4x4 T4000 Atv/Utv Winch

Drinking water Immune seals. 1.6 HorseEnergy DC Long term magnet Engine. 3 Phase planetary Items Program.
Quick retrieval 198-1 Items Percentage. Automated Body weight holding brake in drum. 4 roller fairlead.
Cable rope is 6/25″ x 32′ Extended. Common ATV / UTV Battery pack Operates Properly. Reduced amperage Usage.
12′ hand controller. Outdoors dimensions are: 13.15″ L x 4.49 W x 4.72 H.
Common mounting Routine of 4.88″ x 3″. Body weight is: 22 lbs
Created to be Utilised for the Bigger ATV, small suv winch and Vehicle, Motorboat, multi Function Power trailers. This electric winch 4x4 has a Greater Degree of Capacity for Individuals who Need the Additional Energy for tougher Work. Very simple and Uncomplicated to use, this electric clutch winch will make your Evening smoother when hauling a Body weight on Panel or when Utilised for Do it yourself Recuperation.

Winch according to the needs of customers design and manufacture

Fromwinch series electric winch adopts electric motor with brake, and other high quality parts so that the winch can perform well. Apart from the standard configuration, it can also be designed and manufactured into special one according to customers' specifications.
This electric atv utv winch is compact in structure and reliable in performance. It can start working effectively, with little noise made during the operational process. It is also easy to install and doesn't need to be maintained frequently, which brings great convenience for the client. Hence, this electric winch has now been broadly applied in ship and deck machinery, as well as construction machinery.
We have stepped towards unlimited success and the credit goes to our entire team who has spent their time and efforts to make us stand in stiff market place. Our product electric power winches, has found a large number of users who have appreciated the quality of this product.

Fromwinch are the well known manufacturers and electric winch manufacturers

Fromwinch are the well known manufacturers and electric winch manufacturers. Fabricated from best quality raw material our range is appreciated for dimensional accuracy, robust construction and operational efficiency.  The electric winch offered by us are used in repair jobs and to carry out erections. The winches can also be custom made in accordance with the load lifting capacity.
We are also involved in offering a quality range of Electric Winch for our clients. These are made using excellent quality raw material and cutting edge technology. After getting manufactured, these are subjected to stringent quality checks that ensure their compliance with the set standards of quality. Moreover, these are used for pulling and lifting loads to high heights.

Few winch accessories on a 4x4

Few winch accessories on a 4x4 provide as great a feeling of security as a winch. You can have a rig running the biggest engine, trickest suspension, and nastiest tires, but it's that winch on the front that you count on when those other components fail to keep your 4x4 moving.
Winches have been a mainstay of four-wheeling adventurers longer than many of us have been alive. During that time they have evolved to become a valued tool, often purchased once and then moved from rig to rig. Today there are numerous manufacturers of winches that are designed primarily for pickup and sport/utility use.
8800lbs 12V electric winch designed for trucks, jeeps, 4x4 off road, and modified vehicles used in self-recovery. Works well for car and boat towing trailers, Tractors, Forestry, Police and Fire department work. Can also be used in light industrial applications.

The weight of the winch can vary somewhat

The weight of the winch can vary somewhat.  If you're primary consideration is to keep weight down, you may want to pay attention to those specifications.  More important may be the dimensions of your twin motor winch.  There are many aftermarket bumpers where the winch mounts internally.  Therefore size may matter.  Of the many different types of winches on the market, the sizes and dimensions can vary considerably.
Solenoid mounting can be a major consideration.  Winches can either have an Integrated or Remote Solenoid pack. A remote solenoid is externally mounted off of the winch. An integrated solenoid is part of the winch either within a "bridge" over the heavy duty winch cable or mounted else where on the winch such as above the motor. There are benefits to both types of solenoid mounting options.  With space restrictions a remote solenoid can reduce the space require to mount the winch itself while the solenoid can be mounted remotely while an integrated solenoid offers protection in a compact package.

8800lb 12V electric winch designed for trucks

8800lb 12V electric winch designed for trucks, jeeps, 4x4 off road, and modified vehicles used in self-recovery. Works well for car and boat towing trailers, Tractors, Forestry, Police and Fire department work. Can also be used in light industrial applications.
Purchasing a winch can be a daunting task especially if you are on a budget. Considering the job of a winch, which is to recover your vehicle when you are sometimes miles for civilization, you must make an educated decision as to which winch you should buy. Then you have to factor in the costs of accessories and mounting options that go along with a winch.  You may even have to consider upgrades to your vehicle such as a better battery and alternator of yours are marginal.  Like a fire extinguisher, you hope you never need it but when you do need to winch out of a sticky situation, you don't want to doubt the choices you made.  So it's wise to educate yourself about the fundamentals of a winch so that you can buy the one that is best for your purpose.  We hope this winch guide may help to explain the different types of winches and the competition auto Winch in order to help you make an educated decision with possibly one of the larger purchases for 4x4.

With plenty of power to assist in atv utv winch

With plenty of power to assist in car electric winch, traversing rough terrain or loading a boat, this electric ATV winch is a reliable and safe addition to any off-roading adventure. A remote switch makes this electric winch easy to use even when you're alone! Features include a single-stage planetary gear system for fast line speed, aircraft grade wire rope and a permanent magnet motor that draws less current making it perfect for ATV use.
1, Permanent magnet motor draws less current, ideal for ATV use;
2, Single-stage planetary gear system for fast line speed;
3, Automatic load-holding brake for maximum safety;
4, Free spooling for fast line-out;
5, Roller fairlead with nylon bushing.

tungsten4x4 winch is made from top-grade materials

tungsten4x4 winch is made from top-grade materials and is designed for winches of 8000 lbs thru 12500 lbs.This rope will haul the load safely, without the problem of handling steel wire. It has the ability to stretch with load impacts, and comes without the problem of rusting like a steel heavy duty winch cable. The rope is rated for a breaking strength of 12500 lbs. Compared with a steel cable, it only recoils a little when breaks and is much safer than a metal cable or a chain. Tungsten4×4 synthetic winch rope is lighter and easier to handle than a traditional wire rope.
The winch felt solid and pulled strongly, and performed without any complaints or odd behavior.

8800lb and 9600lb 12V electric winch

8800lb 12V electric winch designed for trucks, jeeps, 4x4 off road, and modified vehicles used in self-recovery. Works well for car and boat towing trailers, Tractors, Forestry,Police and Fire department work. Can also be used in light industrial applications.
9600lb electric winch designed for trucks, jeeps, 4x4 off road, and modified vehicles used in self-recovery. Works well for car and boat towing trailers, Tractors, Forestry, Police and Fire department work. Can also be used in light industrial applications.

Fromwinch has become a professional expert on industry use light duty electric winches

electric winch manufacturers, Fromwinch has become a professional expert on industry use heavy duty electric winches. Lift constructon material for building,service for the hydropower station or to be a lift mechanism as lift trolley for cranes. With our electrics winch you can make a easy and high efficiency working.
Electric winches are used to Push / Pull Loaded trolleys moving on rails. Electric winches come in different shapes and sizes. Electric winches are usually capable of handling loads of 2500lbs to 12500lbs. The cables and motors of electric winches are created specifically to handle different weight loads. Fromwinch designs and manufactures such Electric Winches to suit specific client requirements.

Electric Winches can be made available by us

Electric Winches offered comprises can be made available by us in different pulling capacities from 2500lbs to 12500lbs. Further, these electric wire rope winch can be provided with suitable cable lengths, power cord and remote switch support. Some of its features include suitable for use in vehicle recovery, mining, Constructions, Infra projects, erections of vessels & various other areas. It comes equipped with heavy crane duty gearboxes, precision machined wire rope drums, spooler & tailor made options are also available.
Our Electric winch is known for their superior strength, design, durability and long-term performance. The components are made of best quality materials.

Tungsten has winches and related recovery accessories

Off-roading can make many of us feel invincible as we tear through rough, rugged terrains, but even the best of us will fall into an occasional scrape. Whether it's a particularly large ditch or a mud pit, off-roading expertise will only get you so far before you need a winch to take over. This compact piece of machinery will do what your large truck, Jeep, or SUV couldn't. So even though you won't use them often (knock on wood), winches are something you just can't go without.
Fromwinch electric winch manufacturers LLC owns two brands, one is "Tungsten4x4" located in the south eastern USA. The second is "Fromwinch ", which is soon to be seen all over the world. Our headquarters are located in Tallahassee, in north west Florida where we personally use what we sell!
Over the many years of continuing improvement, the Tungsten4x4 winch of products first came out in the winter 2013. We proudly supply only high quality and fast service to active dealers and our online customers.
Tungsten has winches and related recovery accessories, mainly to serve our offroad 4x4 hobbyists. Our well known high standards in quality for the ultimate winching performance, coupled with low cost for a great dollar value, will make you love using Tungsten4x4's products in all your favorite outdoor activities.
After two years of development, Fromwinch is now most advanced line we offer, with more performance in electric winches than ever before. Our first launch will be seen at the SEMA Show in November 2nd thru 5th of 2015.

Tungsten4x4 T4000 Utv/Atv Winch

Tungsten4x4 T4000 Utv/Atv Winch
Water resistant seals. 1.6 HP DC permanent magnet motor. 3 stage planetary gear system.
Fast retrieval 198-1 gear ratio. Automatic load holding brake in drum. 4 roller fairlead.
Wire rope is 6/25″ x 32′ long. Standard ATV / UTV battery works well. Low amperage consumption.
12′ hand controller. Outside dimensions are: 13.15″ L x 4.49 W x 4.72 H.
Standard mounting pattern of 4.88″ x 3″. Weight is: 22 lbs
Atv utv winch designed to be used for the larger ATV, UTV and car, boat, multi purpose utility trailers. This compact winch has a higher level of ability for those who require the extra power for tougher jobs. Simple and easy to use, this winch will make your day smoother when hauling a load on board or when used for self recovery.

Trailer winches let you pull your boat onto the trailer

Trailer winches let you pull your boat onto the trailer while it’s on an inclined launching ramp. Winches are mounted on a dedicated winch stand on the trailer tongue, on the support for the bow stop or on the trailer’s hitch ball using an adapter plate. A reel or spool holds 20-50 feet of cable, rope or webbing, and has a snap at the bitter end. With the snap clipped onto the bow eye of the boat, the winch operator can either crank the boat onto the trailer or allow the boat to slide backwards into the water at a controlled rate.
Electric winches use rugged DC motors, powered by the tow vehicle’s battery and electrical system. Using low-stretch steel cable to connect to the boat, some electric winch 4x4 use a pulley or block at the boat’s bow eye to double the pulling power (which doubles the cable length and halves the retrieval speed).
Manual winches multiply your strength, allowing you to pull a relatively heavy boat against gravity and friction. They also have a ratchet to hold the boat at any point on the trailer so it doesn’t slide back into the water, allowing a normal person to retrieve a boat weighing over a ton, using a crank about a foot long and simple gearing. Larger models have a lower gear ratio to multiply your strength even more and two speeds for extra power.

Your electric lift winch has incredible potential

Your electric lift winch has incredible potential if you know how to get the most power out of it. With these advanced heavy duty  winch techniques, you'll have a few more tricks up your sleeve when the pulling gets tough.
Another trick to squeeze the most power out of your winch is to gas the stuck vehicle. A rolling load fuels the momentum of the pull and eases the strain on your winch. Before starting the recovery, dig out around the tires or build a rock ramp to give the stuck vehicle some traction as it begins to move.
As your winch works harder, it generates more heat. In order to prevent overheating the motor, take breaks if you're pulling over a long distance and let the motor cool before starting again. Winching places a heavy load on your electrical system, so keep your engine running to prevent a complete drain. In some cases, a stock battery may not provide enough juice to power a maximum pull. Some wheelers swap the stock battery for a heavy duty one, or they install a second battery solely for recovery.

If you want to double the power of your winch

If you want to double the power of your winch, or if the anchor point is too close to let out enough cable for a strong pull, use a snatch block to double the line. Using a winch snatch block will double your load capacity and will allow you to spool out more cable to reach the maximum rating of your winch. For even more power, you can rig up a triple line pull. However, use caution with double and triple lines. As the strength of the pull increases, so does the amount of stress placed on each rigging point. Make sure your anchor point is rock solid and can withstand the force of the pull.
The length of cable you spool out also affects the power of the pull. All electric winches are rated based on only one full wrap left on the drum. The less line you reel out, the less power you'll get. For a maximum power pull, unwind enough cable to leave only one layer on the drum. If your anchor point is too close to spool out enough rope, double the line with a snatch block.

An electric winch is a powerful recovery tool

An electric winch is a powerful recovery tool. Used correctly, it provides massive amounts of power to pull out your ATV or truck. With the right tools and rigging, you can pull up to two or even three times the maximum rating of your winch. The key to maximum power is knowing how to use your recovery equipment to its full potential. With these recovery tips, you'll be winching your way out of even the toughest spots just like the pros.
For starters, let's focus on rigging up a single line pull. Whenever possible, choose an anchor point directly in line with the stuck vehicle. A straight line pull is more efficient than an indirect pull. If the only option is to winch at an angle, use a snatch block to guide the cable directly into the winch and prevent it from stacking up on one side of the drum. Attach the cable as low as possible on the anchor point for the best leverage. The base of a tree, stump, or rock is generally the strongest point.
